Avian Carbon Handlebars / Black / 3 inch

Avian Carbon Handlebars / Black / 4.5 inch

Avian Carbon Handlebars / Black / 7 inch

Description

Are you looking for that extra edge by saving weight where you can? If your rider is a little tacker, then the Avian Carbon Handlebar in 3 and 4.5" rises will stiffen up the cockpit and shave a a few grams, or more, from the front end. With an understated aesthetic, like most Avian products, they are manufactured from UD matte carbon and carry a gloss black logo.

Features

Standard 22.2mm clamping area. Drops straight into any 22.2mm BMX stem, so there is no shim or oversized clamp to sort out.
UD matte carbon build. Carbon construction stiffens up the front end and shaves grams for a smaller rider, with a gloss black logo on a plain finish.
Two rises, 3 and 4.5 inch. The 3 inch runs 21 inches wide at 162g, the 4.5 inch runs 23 inches wide at 258g.
Three up, six back. 3 degrees of up-sweep and 6 degrees of back-sweep, with a tapered cross bar joining the two ends.
Rider weight limits apply. Maximum suggested rider weight is 43kg for the 3 inch bar and 55kg for the larger sizes.

Specifications

Width: 21" (3" rise), 23" (4.5" rise)
Rise: 3" or 4.5"
Backsweep: 6 degrees
Upsweep: 3 degrees
Clamp diameter: 22.2mm
Material: UD matte carbon, tapered cross bar
Finish: Matte carbon with gloss black logo
Weight: 162g (3" rise), 258g (4.5" rise)
Note: Maximum suggested rider weight 43kg for the 3" model and 55kg for the larger sizes. Torque stem bolts to a maximum of 7nm and always use carbon paste on the bar and stem contact point.
