Highlights

SDS driver swaps sides
9T driver
14mm hollow chromoly axle
Sealed bearings

Description

The Cult Crew SDS Cassette Hub comes with 14mm hollow axle and sealed bearings and offers you solid Cult quality. The Crew SDS Hub comes with a SDS Driver so you can switch it to RHD or LHD.

Features

SDS driver swaps sides. The SDS driver lets you switch the hub between right hand drive and left hand drive, so one hub covers both setups.
9T driver. A 9 tooth driver suits standard BMX gearing without any adaptors.
14mm hollow chromoly axle. The male axle is hollow to save weight and takes an 8mm allen key insert, with 17mm chromoly nuts.
Sealed bearings. Sealed bearings keep grit and water out, so the hub keeps rolling through winter.
Hub guard included. A non-drive side hubguard comes in the box, so the flange is protected from the first grind.

Specifications

Width: 110mm axle width, locknut to locknut
Material: 6061-T6 aluminium hub shell, CrMo cones and nuts
Bearings: Sealed
Driver: 9T SDS, RHD or LHD
Axle: 14mm male hollow CrMo with 8mm allen key insert, 17mm nuts
Included: 1x non-drive side hubguard
Note: Drive side flange diameter 49mm, non-drive side 43mm. Drive side flange to locknut 30mm, non-drive side 29mm.

Spoke calculator

Display

Pick the part it is laced to and we will give you the lengths to buy.

This hub

Looking up its measurements.

Check or change its figures

Hub spacing locknut to locknut, 100 front or 110 rear on most BMX mm Same both sides front hubs, or matching flanges

Flange diameter spoke hole centre to the opposite hole centre. The drive side is the driver side, left or right hand drive alike, and is usually the bigger flange

Drive side mm Non-drive side mm

Flange position

Flange to locknut Centre to flange

Drive side mm Non-drive side mm

Laced to which rim?

Find your rim

Or type its figures

ERD effective rim diameter, from the spec sheet mm
