An Ikon Carbon 20 Inch Brakeless Rim with gold lettering on it.
The Ikon Carbon 20 Inch Brakeless Rim is a black and blue carbon fibre bicycle rim with blue lettering.
A black rim with yellow lettering on it. Incorporates the Ikon Carbon 20 Inch Brakeless Rim.
The Ikon Carbon 20 Inch Brakeless Rim is designed specifically for BMX races, featuring a sleek black and blue design. This rim is not only the lightest option available on the market, but also one of the finest.
An Ikon Carbon 20 Inch Brakeless Rim with blue lettering on it.
A Ikon Carbon 20 Inch Brakeless Rim with blue lettering on it, made of alloy.

Description

The Ikon Carbon 20 inch rims are some of the lightest and strongest BMX race rims available currently from any brand. Using a double walled T700 UD carbon fibre weave manufacturing technique, these rims are just 305 grams.

You only have to look across the gate of any UCI world cup round to see the dominance of carbon fibre rims. In fact you would be hard pressed to see any alloy rim these days at this level, or a national cup round here in Australia. The advantages are clear, the strength of these carbon rims means that they take a beating that alloy rims could never stand up to.

This version of the Ikon rim has no braking surface, they are also available without a braking surface here.

Features
  • 300 grams, brakeless. The version without a braking surface, coming in at 300 grams.
  • Double walled T700 carbon. A double walled T700 UD carbon fibre weave rim, among the lightest and strongest BMX race rims available.
  • For brakeless race builds. Built with no braking surface, so it suits a race bike that runs without a rim brake.
  • 36 hole, Presta valve. Drilled 36 hole with a Presta valve hole and an ERD of 377.4mm for spoke length calculations.
  • 25mm internal rim width. 32mm external and 25mm internal width at 25mm deep, sized for 20 x 1.50 and 1.75 inch tyres.

Specifications
  • Wheel size: 20" x 1.50"/1.75", ETRTO 406mm
  • Material: T700 UD carbon fibre, double walled
  • Hole count: 36
  • Rim width: 32mm external, 25mm internal
  • Rim depth: 25mm
  • Brake surface: None, brakeless
  • Valve: Presta (F/V)
  • Weight: 300 g
  • Note: ERD 377.4mm

Spoke calculator

Pick the part it is laced to and we will give you the lengths to buy.

This rim

Looking up its measurements.

Check or change its figures

Laced to which hub?

Or type its figures

Flange diameter spoke hole centre to the opposite hole centre. The drive side is the driver side, left or right hand drive alike, and is usually the bigger flange

Flange position

Spoke lengths to buy

Drive side —mm
Non-drive side —mm

Pick the hub and your lengths will appear here.

Open the full spoke calculator for offset rims, other cross patterns and measuring help.

Ikon Carbon 20 Inch Brakeless Rim

Brand: Ikon SKU:

From

$439.99 AUD

 $599.99 AUD

Or 4 payments of $109.99 AUD with

Colour - Black/Sand

Spoke Holes - 36 Hole

Ikon Carbon 20 Inch Brakeless Rim - Black/Sand / 36 Hole

Discount 27%

Instead of $599.99

$439.99 AUD

Price match request

$12.99 flat-rate shipping Australia-wide

Express from $21.99

Free in-store pickup - Brisbane

Availability

36 Hole
Black/Sand
Black/Blue
Black/Yellow

● In stock at LUXBMX ● With supplier ● Preorder ○ Sold out
