SMFR095

Highlights

  • 21.75" top tube, 24 inch
  • Adjustable 14.7" to 15.5" rear
  • Mid bottom bracket, ez-out slots
  • Integrated campy style head tube

Description

The ATF24 is S&M's 24 inch frame, built around a 21.75" top tube, a 74.5° head tube angle and a 71° seat tube angle.

The rear end runs from 14.7" to 15.5", the bottom bracket sits at 13" with a 9.5" standover, and the frame weighs 2.51kgs on 14mm dropouts.

Features
  • 21.75" top tube, 24 inch. A full size 24 inch frame with a 74.5° head tube angle and a 71° seat tube angle.
  • Adjustable 14.7" to 15.5" rear. Move the wheel in the 14mm dropouts to set the back end short and snappy or long and stable.
  • Mid bottom bracket, ez-out slots. Punch slots in the shell make getting the bearings back out straightforward.
  • Integrated campy style head tube. Takes an integrated headset up front, with a 1" (25.4mm) seat post at the other end.
  • Thread on 990 brake mounts. The mounts thread on when you want a brake and come off when you do not, and are sold separately.

Specifications
  • Top tube: 21.75"
  • Chainstay: 14.7" to 15.5"
  • Head tube angle: 74.5°
  • Seat tube angle: 71°
  • Standover: 9.5"
  • Bottom bracket height: 13"
  • Bottom bracket: Mid, with ez-out punch slots
  • Dropouts: 14mm
  • Brake mounts: Thread on 990, mounts sold separately
  • Head tube: Integrated, campy style
  • Seat tube: 1" (25.4mm) post
  • Wheel size: 24"
  • Weight: 2.51kgs

S&M ATF24 24 Inch Frame

Brand: S&M SKU:

$999.99 AUD

Or 4 payments of $249.99 AUD with

Colour - Matt Black

Top Tube Length - 21.75

S&M ATF24 24 Inch Frame - Matt Black / 21.75

$999.99 AUD
