Highlights

Front hub for 20mm forks
Answer 20mm axle included
EZO bearings inside
36 hole drilling

Description

The Answer Front 20mm Thru-Bolt Pro Hub is the perfect stable mate for Answer's Pro Disc hub if you're running a 20mm fork. Not pictured, but included is the Answer 20mm axle.

Features

Front hub for 20mm forks. Built around a 20mm thru-bolt axle, so it suits race forks running the larger front axle rather than a standard 3/8 inch.
Answer 20mm axle included. The axle comes in the box, so there is nothing else to chase before you lace it up.
EZO bearings inside. Runs EZO bearings, so the front wheel keeps spinning freely lap after lap.
36 hole drilling. Flange diameter is 58mm with 32.5mm centre to flange, which is everything a spoke calculator needs for a 36H build.
215 grams, hub only. The hub body is CNC machined to pull weight out, and it measures 100mm across.

Specifications

Fits: Forks running a 20mm thru-bolt front axle
Width: 100mm hub width
Bearings: EZO
Hole count: 36H
Axle: Answer 20mm axle, included
Included: Answer 20mm axle
Weight: 215g (hub only)
Note: Flange diameter 58mm, centre to flange 32.5mm. Pairs with the Answer Pro Disc rear hub.

Spoke calculator

Display

Pick the part it is laced to and we will give you the lengths to buy.

This hub

Looking up its measurements.

Check or change its figures

Hub spacing locknut to locknut, 100 front or 110 rear on most BMX mm Same both sides front hubs, or matching flanges

Flange diameter/PCD (pitch circle diameter) spoke hole centre to the opposite hole centre. The drive side is the driver side, left or right hand drive alike, and is usually the bigger flange

Drive side mm Non-drive side mm

Flange position

Flange to locknut Centre to flange

Drive side mm Non-drive side mm

Laced to which rim?

Find your rim

Or type its figures

ERD effective rim diameter, from the spec sheet mm
