All Box One forks are engineered and crafted using Box's Oversized Technology. These forks are the single most important component in the quest for bike control. Box has moved carbon from areas of low stress to areas that handle high load. Those muscular shoulders aren’t just for looks as they are integral to achieving superior steering stiffness. When combined with Box’s other Oversized components, you’ll experience heightened responsiveness and reduced latency.
Key differences: This model built off of Box's title winning X5 platform and carries race developed Oversized Technology, as well as featuring a 1.5 to 1-1/8 inch alloy steerer tube. Designed with increased tire clearance and larger hips, it delivers enhanced stiffness and performance. The inclusion of robust 20mm thru axle cold-forged dropouts ensures maximum durability and stability. Say goodbye to deflection and hello to race winning performance.
Weight Limit: 115kg
Specifications
Material:
• Legs: High Modulus Unidirectional Carbon Fiber
• Steerer: 7075-T6 Aluminum
• Butterfly & Dropouts: 6061-T6 Aluminum
Process:
• Legs: Vacuum Mold
• Steerer: Extruded & CNC
• Butterfly & Dropouts: Cold-Forged
Hardware: Stem Lock
Finish: Gloss Black with White Decals
Compatibility/Size:
• Height: 20”
• Steerer: 1-1/8" tapers to 1.5"
• Offset: 32mm
• Dropouts: 20mm
Height
• Axle to Crown: 20” 303mm
Weight
• 20”: 625g
