Chase Edge Expert Bike (2022) / Blue/Red / 19.75TT

Description

Chase Bicycles have really knocked it right out of the park with their 2022 Edge range. Moving up in their 20 inch bike line up from the minis and juniors, you'll find the Chase Edge Expert. The last of the bikes on the "skinny tyres", the 2022 Chase Edge Expert bike packs a punch coming spec'd straight from the factory with a disc brake and with what we predict will become the norm for braking. Your young racer will start out on the very best in performance with the frame on the brand's Edge Expert manufactured with the same hydroformed and triple butted tubing as the bigger bikes in the range, and includes features like enclosed dropouts. The part's list mirrors quality like that of its bigger brothers as well, with Chase Edge CroMo forks, Tioga PowerBlock 20 x 1-3/8th tyres, Insight chainring, grips and Chase Edge pivotal pro seat.

With dedicated race geometry and lightweight design, the Chase Expert race bike is just the ticket for the emerging racer moving up into the age class racing ranks and is biting at the bit to start sending gaps out there just like the big kids. Get ready to be tagging #winwithchase regularly as your racer enters the winning arena. All in all, this is one of the coolest, highest spec'd expert race bikes currently available on the market and will set up your young rider for a life of BMX racing on of the most developed complete expert race bikes to date. Bang for buck. Hard to go past this expert bike.

Features

Disc brake from the factory. A 140mm rotor and mechanical disc calliper come stock, the setup we predict will become the norm for race braking.
Same tubing as the big bikes. Triple butted hydroformed 6061 T6 alloy frame with enclosed rear dropouts and an integrated chain tensioner, built from the same tubing as the bigger Chase bikes.
Last of the skinny tyres. Tioga PowerBlock 20 x 1-3/8" tyres on Chase Edge 118 double wall rims, 24H front and 28H rear, on the last Edge model to run the skinny race tyre.
Chase Edge 165mm 3-piece cranks. Alloy 165mm arms with CrMo chainring bolts, an Insight 42T chainring and 16T cog for 42 x 16 gearing (54.88") on a Euro sealed bottom bracket.
Race geometry, 8.47 kg. Full CrMo Chase Edge fork, sealed Chase Edge Mini hubs with a 3-pawl cassette clutch, Insight C.O.G.S grips and a Chase Edge Pro Pivotal seat, 8.47 kg without pedals.

Specifications

Size: 20" wheels, 19.75" top tube
Frame: Chase Edge Expert, triple butted hydroformed 6061 T6 alloy, enclosed rear dropouts, integrated chain tensioner system
Top tube: 19.75"
Fork: Chase Edge Expert, full CrMo, 1-1/8" steer tube
Headset: Integrated sealed bearing
Stem: Chase Edge 50mm
Bars: Chase Edge, 5.75" rise, 25.5" wide, 8° back sweep, 2° up sweep
Grips: Insight C.O.G.S 130mm, alloy clamps, laser etched logo, PVC end plug
Brakes: Rear mechanical disc calliper, 140mm rotor
Brake lever: Linear-pull lever
Cranks: Chase Edge 3-piece, 165mm alloy arms, laser etched logo, CrMo chainring bolts and nuts
Bottom bracket: Euro sealed
Chainring: Insight 42T, 5 bolt, 110mm BCD
Pedals: Alloy sealed
Front hub: Chase Edge Mini, 3/8" axle, sealed bearings
Rear hub: Chase Edge Mini, 3/8" axle, sealed bearings, steel cassette body, 3-pawl triple angle engagement clutch on a 24T ratchet, ISO disc mount
Rear cog: 16T
Rims: Chase Edge 118 double wall, 20" x 1-3/8", 24H front and 28H rear
Tyres: Tioga PowerBlock 20" x 1-3/8" front and rear
Seat: Chase Edge Pro Pivotal
Gearing: 42 x 16 (54.88" gear)
Weight: 8.47 kg (without pedals)

Assembly information

Your race bike ships mostly assembled in the box. Finishing it takes most people 10 to 20 minutes with basic tools, and the video above walks through every step.

Fit the handlebars and line them up with the front wheel
Fit the front wheel, pedals and seat post
Spin the rear wheel and check the rotor runs clear of the calliper
Check the brake and tyre pressure before the first ride

Disc brakes: keep your fingers off the rotor and pads, because oil from your skin contaminates the braking surface and takes the bite away. If the rotor rubs, loosen the two calliper bolts, squeeze the lever, then tighten them again with the lever held on. Bed the brake in with a few firm stops before you race it.

Tools: Allen key set and a 15mm spanner for the pedals. Check your axle hardware, since race bikes vary between bolt-on nuts and a thru-axle.

Rather have it done? Ask us about extra assembly before you order, or any local bike shop can finish the build for a small fee.

Chase Edge Expert Bike (2022)

Name: Chase Edge Expert Bike (2022)
Brand: Chase
SKU: 65CB220204EXPBLU
Price: 1098.99 AUD
Availability: OutOfStock

Brand: Chase SKU: Click to copy the SKU and show the pick location

$1,098.99 AUD

Or 4 payments of $274.74 AUD with

Recommended Rider Height:

130-170cm

Colour - Blue/Red

Top Tube Length - 19.75

Race frames are sized by class, and the class you ride is set by rider height rather than age.

Size	Rider height	Top tube
Micro (18" wheels)	Under 120cm	16.25"
Mini (20" wheels)	110 to 140cm	17 to 18"
Junior	120 to 150cm	18.25 to 18.75"
Expert	130 to 170cm	19.5 to 19.75"
Expert XL	145 to 170cm	20 to 20.75"
Pro	150 to 175cm	20.25 to 20.75"
Pro XL	165 to 180cm	21 to 21.25"
Pro XXL	170 to 185cm and up	21.5 to 21.85"
Pro XXXL	175cm and up	22"
Pro XXXXL	180cm and up	22.5"
Cruiser (24" wheels)	175cm and up	21.5" and up

Heights overlap between classes on purpose. Where you land in two, a growing rider is usually better on the larger, and a rider who wants the bike to turn faster on the smaller. Some brands label the Pro size Pro L, with the same fit.

How to measure

Stand your rider against a wall in the shoes they ride in, heels flat, and mark the top of their head. Measure from the floor to the mark.

Between two sizes and still growing? Take the larger size.
Racing gates and wanting the bike to turn faster? Take the smaller size.
Top tube is the number that actually changes the fit, so compare it against the bike they ride now.

Not sure? Send us their height and we will tell you what we would put them on.
