Highlights

  • First of three Pro sizes
  • Hydroformed, triple butted 6061 T6 frame
  • Disc brake fitted at the factory
  • Tioga tyres on 32H double wall rims

Description

Chase Bicycles have again knocked it right out of the park with their 2023 Edge range. Stepping up to the Pro sized bikes, Chase now offers 3 sizes with this Pro L being the first with its 20.5 inch top tube. The Pro L runs on Tioga Powerblocks (20 x 1.85 front and 20 x 1.60 rear) and double-walled alloy rims, which is the ideal set up and perfect for the emerging young rider that is really starting to push the limits hitting the bigger jumps out on the track. The 2023 Chase Edge Pro L bike packs a punch coming spec'd straight from the factory with a disc brake and with what we predict will become the norm for braking. Your young racer will start out on the very best in performance with the frame on the brand's Edge Pro L manufactured with hydroformed and triple butted tubing and includes features like enclosed dropouts. The part's list includes trusted brands like Insight (chainring, grips) and with alloy three piece cranks and Chase Edge CroMo forks, this Pro bike will take plenty of hits as you explore the limits of your speed and skill.

With dedicated race geometry and lightweight design, the Chase Pro L race bike is just the ticket for the emerging racer moving up from club racing into open events and is really starting to see some serious results. Get ready to be tagging #winwithchase regularly as your racer enters the winning arena. All in all, this is one of the coolest, highest spec'd Pro L race bikes currently available on the market and will set up your adolescent rider for a life of BMX racing on of the most developed complete Pro L race bikes to date.

By far one our best selling brands in 2022, we expect the 2023 Chase Edge models to sell just as quick as they are definitely one of the best club level race bikes out there. Bang for buck, it's hard to go past this expert bike.

Features

  • First of three Pro sizes. The Pro L's 20.5" top tube suits the emerging young racer moving up from club racing into open events.
  • Hydroformed, triple butted 6061 T6 frame. Dedicated race geometry in a lightweight alloy frame with enclosed rear dropouts and an integrated chain tensioner system.
  • Disc brake fitted at the factory. Mechanical disc calliper on a 140mm rotor with a linear-pull lever, the braking we predict will become the norm on race bikes.
  • Tioga tyres on 32H double wall rims. PowerBand 20 x 1.85 front and PowerBlock 20 x 1.60 rear on Chase Edge 150 rims, the ideal set-up for pushing into the bigger jumps on the track.
  • Chromoly fork and sealed bearings. Tapered-blade Chase Edge Pro fork, sealed hubs, headset, Euro BB and pedals, 175mm three-piece alloy cranks and Insight alloy clamp grips, 9.37kg without pedals.

Specifications

  • Size: 20" wheels, 20.50" top tube
  • Frame: Chase Edge Pro L, triple butted hydroformed 6061 T6 alloy, enclosed rear dropouts, integrated chain tensioner system
  • Top tube: 20.50"
  • Fork: Chase Edge Pro, full chromoly, 1-1/8" steerer tube with tapered blades
  • Headset: Integrated sealed bearing
  • Stem: Chase Edge 50mm, 6061 T6 alloy, laser etched logo
  • Bars: Chase Edge 22.2mm, 7.5" rise, 27" wide, 11° back sweep, 3.5° up sweep
  • Grips: Insight C.O.G.S 130mm, alloy clamps, PVC end plugs
  • Brakes: Rear mechanical disc calliper, 140mm rotor
  • Brake lever: Linear-pull lever
  • Cranks: Chase Edge 3-piece, 175mm alloy arms, laser etched logo, chromoly chainring bolts and nuts
  • Bottom bracket: Euro, sealed
  • Chainring: Insight 43T, 4 bolt, 104mm BCD
  • Pedals: Alloy, sealed
  • Front hub: Chase Edge Pro, 3/8" axle, sealed bearings
  • Rear hub: Chase Edge Pro, 3/8" axle, sealed bearings, steel cassette body, 3 pawls at triple angle engagement for 24T ratchet, ISO disc mount
  • Rear cog: 16T
  • Rims: Chase Edge 150 double wall, 20" x 1.50", 32H front and rear
  • Tyres: Tioga PowerBand 20" x 1.85" front, Tioga PowerBlock 20" x 1.60" rear
  • Seat: Chase Edge Pro Pivotal
  • Seat clamp: Chase Edge QR alloy, 31.8mm
  • Gearing: 43 x 16 (52.37" gear ratio)
  • Weight: 9.37kg (without pedals)

Assembly information

Your race bike ships mostly assembled in the box. Finishing it takes most people 10 to 20 minutes with basic tools, and the video above walks through every step.

  • Fit the handlebars and line them up with the front wheel
  • Fit the front wheel, pedals and seat post
  • Spin the rear wheel and check the rotor runs clear of the calliper
  • Check the brake and tyre pressure before the first ride

Disc brakes: keep your fingers off the rotor and pads, because oil from your skin contaminates the braking surface and takes the bite away. If the rotor rubs, loosen the two calliper bolts, squeeze the lever, then tighten them again with the lever held on. Bed the brake in with a few firm stops before you race it.

Tools: Allen key set and a 15mm spanner for the pedals. Check your axle hardware, since race bikes vary between bolt-on nuts and a thru-axle.

Rather have it done? Ask us about extra assembly before you order, or any local bike shop can finish the build for a small fee.

Chase Edge Pro L Bike

Brand: Chase SKU: Click to copy the SKU and show the pick location

Sale price$1,249.99 AUD

Or 4 payments of $312.49 AUD with

Recommended Rider Height: 150 to 175 cm

Colour - Blue

Top Tube Length - 20.5

BMX race bike sizing

Race frames are sized by class, and the class you ride is set by rider height rather than age.

SizeRider heightTop tube
Micro (18" wheels)Under 110cm16.25"
Mini (20" wheels)110 to 125cm17 to 18"
Junior120 to 140cm18.25 to 18.75"
Expert135 to 155cm19.5 to 19.75"
Expert XL150 to 165cm20 to 20.75"
Pro160 to 170cm20.25 to 20.75"
Pro XL165 to 175cm21 to 21.25"
Pro XXL170 to 185cm and up21.5 to 21.85"
Pro XXXL175 to 185cm and up22"
Pro XXXXL185cm and up22.5"
Cruiser (24" wheels)175cm and up21.5" and up

Heights overlap between bike sizes on purpose. If you fall in two size categories, a growing rider new to racing is usually better suited to the larger bike, a experienced rider who wants the bike to more responsive should err on the smaller size. Some brands label the Pro size Pro L, with the same fit.

How to measure

Stand your rider against a wall in the shoes they ride in, heels flat, and mark the top of their head. Measure from the floor to the mark. Just don't guess their height either, you know how fast they can grow!

Here are some tips

  • Between two sizes and still growing? Take the larger size, but make sure you check the top tube length of the bike. The length of top tube for a given size (Expert XL as an example) can vary up to a half inch or more across brands. Most Expert XL frames are 20", but we've seen them as long as 20.7"
  • Experienced racer and wanting the bike to be more responsive? Take the smaller size. You want the bike to be "under you", not a stretch to the bars and cranks.
  • Top tube is the number that actually changes the fit, so compare it against the bike they ride now.

Still not sure? We're the experts and size bikes for riders every day of the week. Our team has decades of experience between them and will help you decide which bike is the right fit based on rider height and racing experience.

BMX race bike sizing

Race frames are sized by class, and the class you ride is set by rider height rather than age.

SizeRider heightTop tube
Micro (18" wheels)Under 110cm16.25"
Mini (20" wheels)110 to 125cm17 to 18"
Junior120 to 140cm18.25 to 18.75"
Expert135 to 155cm19.5 to 19.75"
Expert XL150 to 165cm20 to 20.75"
Pro160 to 170cm20.25 to 20.75"
Pro XL165 to 175cm21 to 21.25"
Pro XXL170 to 185cm and up21.5 to 21.85"
Pro XXXL175 to 185cm and up22"
Pro XXXXL185cm and up22.5"
Cruiser (24" wheels)175cm and up21.5" and up

Heights overlap between bike sizes on purpose. If you fall in two size categories, a growing rider new to racing is usually better suited to the larger bike, a experienced rider who wants the bike to more responsive should err on the smaller size. Some brands label the Pro size Pro L, with the same fit.

How to measure

Stand your rider against a wall in the shoes they ride in, heels flat, and mark the top of their head. Measure from the floor to the mark. Just don't guess their height either, you know how fast they can grow!

Here are some tips

  • Between two sizes and still growing? Take the larger size, but make sure you check the top tube length of the bike. The length of top tube for a given size (Expert XL as an example) can vary up to a half inch or more across brands. Most Expert XL frames are 20", but we've seen them as long as 20.7"
  • Experienced racer and wanting the bike to be more responsive? Take the smaller size. You want the bike to be "under you", not a stretch to the bars and cranks.
  • Top tube is the number that actually changes the fit, so compare it against the bike they ride now.

Still not sure? We're the experts and size bikes for riders every day of the week. Our team has decades of experience between them and will help you decide which bike is the right fit based on rider height and racing experience.
