• Made for the long haul. Happy as a weekday commuter on rough city roads, but it really shines when you take it away for days.
• 100% chromoly frame and fork. Steel that welcomes virtually anything you throw at it, with rack and fender mounts so you can load it up.
• SRAM Apex 1 11-speed drivetrain. An 11-42T cassette and 42T narrow-wide chainring give you a wide spread of gears for loaded climbs and flat road speed.
• Avid BB7 Road disc brakes. Cable disc brakes with SRAM Apex 1 levers, so stopping stays consistent when the roads turn wet or steep.
• Maxxis Pace 27.5 x 2.1" tyres. Semi-knobby rubber on tubeless compatible double wall rims, with frame clearance to swap to 700c wheels later.

• Size: L and XL, 27.5" wheels
• Frame: 100% chromoly steel, rack and fender mounts, L is 700c compatible
• Top tube: Effective 579mm (L), 602mm (XL); actual 559mm (L), 585mm (XL)
• Chainstay: 440mm
• Head tube angle: 71.5°
• Seat tube angle: 73°
• Standover: 800mm (L), 830mm (XL)
• Fork: 100% chromoly, one-piece machined steerer tube, 416mm length, 50mm offset
• Headset: FSA, sealed integrated, 45º/45º
• Stem: 6061-T6 forged aluminium, 80mm (L and XL)
• Bars: FSA NS Adventure, 420mm (L), 440mm (XL)
• Grips: Fairdale Cork handlebar tape
• Brakes: Avid BB7 Road
• Brake lever: SRAM Apex 1
• Cranks: SRAM Apex 1, 172.5mm (L), 175mm (XL)
• Bottom bracket: Neco BB-501, English 68
• Chainring: 42T narrow-wide
• Chain: KMC X11
• Pedals: Odyssey Twisted PC
• Front hub: Sealed bearings, 32H, alloy shell, disc brake mount, allen skewer axle
• Rear hub: Sealed bearings, 32H, alloy shell, disc brake mount, allen skewer axle, 135mm spacing
• Rims: 650b, 32-hole, aluminium, double wall, tubeless compatible
• Tyres: Maxxis Pace 27.5" x 2.1"
• Seat: Fairdale Race
• Seat post: Micro adjust, 27.2mm
• Seat clamp: Fairdale, 30mm
• Gearing: SRAM Apex 1 11-speed: PG-1130 11-42T cassette, Apex 1 long cage rear derailleur and shifter, Fairdale cable with jagwire inline adjuster
• Note: Large suits 5'9" to 6'1", X-Large suits 6'1" and above. Wheelbase 1058mm (L), 1081mm (XL). BB drop 72mm. Approximate max tyre width 54mm on 27.5"/650b, 53mm on 29"/700c.

Your bike ships mostly assembled in the box. Finishing it takes most people 10 to 20 minutes with basic tools, and the video above walks through every step.

• Fit the handlebars and line them up with the front wheel
• Fit the front wheel, pedals and seat post
• Check the brakes and tyre pressure before the first ride

Tools: Allen key set and a 15mm, 17mm or 19mm spanner for the pedals and axle nuts (bikes can vary between these three sizes). A socket is needed if installing pegs.

Rather have it done? Ask us about extra assembly before you order, or any local bike shop can finish the build for a small fee.
