Description

The French revolution in BMX racing started long ago when they travelled to the USA in the early to mid 90s and soo established a reputation for being some of the smoothest, and fastest riders on the planet. This reputation is as valid today with the French taking all 3 medals at the past Olympics.

The French build their tracks deep and steep which demands a frame with geometry that can handle the speed, and be responsive, the 2026 Inspyre V3 frame series fulfils this design criteria, with some of the fastest riders in the world slinging these around on the World Cup circuit.

Variable wall thickness of the hydroformed tubes means that these frames are stiff right where they need to be, while retaining near lightness of a carbon frame, but at a substantial lower price point.

Additional frame stiffness in the Pro sizes is created by using a  larger seat tube, and a CNC'd head tube adds a aerodynamic flavour to the overall design of the V3 frame. The youngsters get their own design tweaks with the Junior, Expert and Expert XL frames running thinner tubing allowing these frames to be exceptionally light and not quite as stiff. After all, the young crew aren't quite pumping our 2000 watts, yet!

At the rear end, according to Inspyre
"The SWELL rear dropout system has been completely redesigned for a better user experience. The SWELL V2 dropouts provide a real 25 mm adjustment range. The internal aluminium 7075-T6 plates in the dropouts stay in place even when the wheel is removed, ensuring optimal ease of use during maintenance. The chain tensioning system uses two CNC-machined adjusters mounted on a stainless-steel axle. The disc brake mount follows the postmount standard for a 120 mm disc, but it is possible to use a 140 mm disc with a +20 mm spacer. The dropout comes standard with a 15 mm thru-axle (sold separately). 15mm to 10mm adapters are included with the frame."

Comment from the LUX LAB workshop - "These are bloody nice frames to build up, and the dropout system does what it says on the tin. It works and is easy to install and adjust. Other frame companies should take note" Ev, LUX co-owner and BMX tech guru.

Features

  • Thinner tubing for junior riders. The Junior frame runs lighter tube walls than the Pro sizes, so a smaller rider has less bike to push out of the gate.
  • Hydroformed 6061-T6 aluminium frame. Variable wall thickness keeps the frame stiff where it takes load, close to carbon weight at a much lower price.
  • SWELL V2.1 dropouts, 25 mm range. Internal 7075-T6 aluminium plates stay in place with the wheel out, and two CNC adjusters on a stainless axle set the chain.
  • Post mount hydraulic disc tab. Standard for a 120 mm disc, and a 140 mm rotor fits with a +20 mm spacer if you want more stopping power.
  • Junior geometry on 451mm wheels. 18.45 Inch top tube, 13.7 Inch chainstay, 73 degree head angle and a Euro BSA 68mm bottom bracket shell.

Specifications

  • Top tube: 18.45 Inch
  • Chainstay: 13.7 Inch (centre)
  • Head tube angle: 73 degrees
  • Seat tube angle: 70 degrees
  • Bottom bracket: Euro BSA 68mm
  • Material: 100% aluminium 6061-T6
  • Tubing: Hydroformed, multiple wall thicknesses. Thinner tubing on the Junior sizes
  • Dropouts: SWELL V2.1 enclosed 10mm/15mm, 25 mm adjustment range, ADS chain tensioner
  • Brake mounts: Disc, post mount hydraulic only: 120 mm disc, or 140 mm with a +20 mm spacer
  • Head tube: Integrated 1-1/8 (110mm)
  • Seat tube: 22.2mm
  • Seat clamp: 25.4mm
  • Axle: 15mm rear thru-axle, sold separately. 15mm to 10mm adapters included
  • Wheel size: 451mm, 20x1-3/8
  • Note: Sold as a frame only, no fork included

Inspyre 2026 Concorde V3 Junior Frame

Brand: Inspyre SKU: Click to copy the SKU and show the pick location

Sale price$999.99 AUD

Or 4 payments of $249.99 AUD with

Colour - Midnight Black

Top Tube Length - 18.45


$999.99 AUD

Price match request

Inspyre 2026 Concorde V3 Junior Frame - Midnight Black / 18.45

$12.99 flat-rate shipping Australia-wide

Express from $21.99

Free in-store pickup - Brisbane

Availability

18.45
Black/Chameleon
Black/Galactic Irridium
Midnight Black

In stock at LUXBMX With supplier Preorder Sold out
