Description

These brand new hubs are super stylish, sound good and are from Odyssey- so you know they are built to last! These hubs are also a switchable design meaning that you can easily change it over from RHD to LHD whenever you feel like changing things up! The C5 is a strong, drive switchable, affordably priced cassette hub with a 14mm chromoly male axle. The LHD/RHD compatible 9T driver rolls on three precision, sealed cartridge bearings. A replaceable plastic hub guard is included.

- 14mm, 4130 chromoly hollow axle, w/6mm hex broaching

- RHD/LHD switchable

- 6802 sealed cartridge driver bearings (3)

About the Brand

Odyssey BMX is dedicated to quality and innovation. Odyssey has been a major player in the BMX industry for a long time now and has produced some of the most iconic and groundbreaking parts in the sport's history.

Features

36-H, 6061 T-6 aluminum hub shell

14mm, 4130 chromoly hollow axle, w/6mm hex broaching

9T driver with 3-Pawl independent spring design

RHD/LHD switchable

Removable plastic hub guards (compatible with Odyssey/G-Sport hubs)

6802 sealed cartridge driver bearings (3)

6903 sealed cartridge hub shell bearings (2)

Specifications

- Drive Side Effective Flange Diameter: 49mm
- Non-Drive Side Effective Flange Diameter: 49mm
- Drive Side Flange to Center Distance: 27mm
- Non-Drive Side Flange to Center Distance: 30mm

Spoke calculator

Display

Pick the part it is laced to and we will give you the lengths to buy.

This hub

Looking up its measurements.

Check or change its figures

Hub spacing locknut to locknut, 100 front or 110 rear on most BMX mm Same both sides front hubs, or matching flanges

Flange diameter spoke hole centre to the opposite hole centre. The drive side is the driver side, left or right hand drive alike, and is usually the bigger flange

Drive side mm Non-drive side mm

Flange position

Flange to locknut Centre to flange

Drive side mm Non-drive side mm

Laced to which rim?

Find your rim

Or type its figures

ERD effective rim diameter, from the spec sheet mm

Spoke count Cross pattern

Spoke lengths to buy

Drive side —mm

Non-drive side —mm

Pick the rim and your lengths will appear here.

Open the full spoke calculator for offset rims, other cross patterns and measuring help.

Odyssey C5 Cassette Hub

Name: Odyssey C5 Cassette Hub
Brand: Odyssey
SKU: ODHU128-01-BLK
Price: 249.99 AUD
Availability: InStock
Rating: 5.0 (1 reviews)
