Finally, an disc version Onyx Hub dedicated to the little speedsters of BMX!
These 28 hole Onyx OHM Race hubs deliver all the benefits of the Sprag Clutch engagement system found in higher end Onyx hubs, at a lighter and more affordable rate for the new generation of riders.
Since the OHM hubs came onto the BMX race scene a few years ago these have dominated the top end of hubs for custom bike builds here at LUX. Frankly, we just don't spec any other hub if you're after the very best in performance. Light weight and with all the trademark precision of Onyx manufacturing, pair these with a set of carbon rims and your young racer is set all the way until they move up to a more heavy duty 36 hole set up.
Specs:
- 28 hole
- Set of front and rear hubs
- 10mm front and rear (Front M8, Rear M10)
- Stainless steel hardware
- Steel cartridge bearings
- HG (Shimano) compatible driver with internal and external lock ring capability
- 120 LB. Rider weight limit
- 465 grams (hub set w/ bolts)
- *Tightening axle bolts more than 15NM will void the warranty
**Doesn't include centre lock hardware.
Dimensions - Front Hub:
- Spoke Count: 28H
- Axle Width: 100mm
-
Hub Center To Flange Center: 33.84mm
- Distance Lock Nut to Flange: 16.16mm
- PCD / Spoke Hole Circle Diameter: 33.81mm
Dimensions - Rear Hub:
- Spoke Count: 28H
- Axle Width: 110mm
- Hub Center To Flange Center, Non-Drive Side: 21.65mm
- Distance Lock Nut to Flange, Non-Drive Side: 33.35mm
- Hub Center To Flange Center, Drive Side: 27.87mm
- Distance Lock Nut to Flange, Drive Side: 27.13mm
- PCD / Spoke Hole Circle Diameter, Non-Drive Side: 42mm
- PCD / Spoke Hole Circle Diameter, Drive Side: 47mm
