Chase Element Pro XXL (2022) / Teal / 21.5TT

Highlights

Sized for the growing Pro racer
RSP geometry in an Element frame
Answer Dagger carbon fibre fork
Hydraulic disc brake from the factory

Description

We expect the 2022 Chase Element Pro XXL bikes to sell as fast as the 2021 models, with the range really establishing itself as the best value for the racer looking to step up from an entry level race bike. With a part's suite that includes gear like race proven Answer carbon fibre Dagger forks, along with a disc brake system, the Element Pro XXL is the perfect race rig for riders coming up through the ranks. The part's list continues with brands like Elevn, Insight and Tioga used for key components

With design cues from the Chase RSP frame series, the Element's geometry has input from Chase's two pro riders, Olympic champion Connor Fields, and 4X USABMX title winner Joris Daudet. The Pro XXL Element with a 21.50" top tube is perfect for the rider jumping up from a Pro L sized bike who's grown enough to skip the Pro XL size. With geometry that mimics Chase's RSP series of frames, this bike is really dialled in and ready to win . Especially with the DNA of the Chase brand in every Element.

Features

Sized for the growing Pro racer. A 21.50" top tube for the rider jumping up from a Pro L who has grown enough to skip the Pro XL.
RSP geometry in an Element frame. Design cues from the Chase RSP series with input from Connor Fields and Joris Daudet, so this one is dialled in and ready to win.
Answer Dagger carbon fibre fork. Race proven carbon up front on a 7005 T6 alloy frame with enclosed rear dropouts and a chain tensioner system built in.
Hydraulic disc brake from the factory. A hydraulic lever and calliper on a 120mm alloy rotor with resin pads, ready to race with no cable to stretch or adjust.
Light race build, 8.955kg. Excess LSP 180mm cranks, Insight 44T ring, sealed Chase Element hubs and Tioga Fastr X tyres on Sun Ringle Envy Lite rims, weighed with pedals.

Specifications

Size: 20" wheels, 21.5" top tube
Frame: Chase Element Pro XXL, 7005 T6 alloy, integrated 1-1/8" head tube, enclosed rear dropouts, chain tensioner system
Top tube: 21.50"
Bottom bracket height: 11.5"
Fork: Answer Dagger Carbon Pro, alloy dropouts, 3/8" axle, 1-1/8" alloy steer tube, alloy top cap
Headset: Chase integrated sealed bearing
Stem: Chase Element 31.8mm, 53mm reach, 6061 T6 alloy, CNC laser etched logo
Bars: Chase Element 31.8mm, 8.5" rise, 28.5" wide, 10° back sweep, 2° up sweep
Grips: Insight C.O.G.S 145mm, alloy clamps, PVC end plug
Brakes: Hydraulic lever and calliper, 120mm alloy disc rotor, resin pads, lock disc adaptor
Cranks: Excess LSP 2 piece, 180mm alloy arms, 4 bolt spider, chromoly pedal inserts, alloy chainring bolts and nuts
Bottom bracket: Press fit 68/73mm, cartridge bearings
Chainring: Insight 44T, 4 bolt, 104mm, 1/2" x 3/32", 5mm alloy ring
Chain: KMC Z1 narrow, 1/2" x 3/32"
Pedals: Nylon platform, 9/16"
Front hub: Chase Element, 3/8" axle, M6 bolts, 36H, sealed bearing
Rear hub: Chase Element ISO, 3/8" axle, M6 bolts, 36H, sealed bearing, steel cassette body with 3 pawls at triple angle engagement for 24T ratchets
Rear cog: 16T
Rims: Sun Ringle Envy Lite 36H, 20 x 1.50", no brake surface, Schrader valve
Tyres: Tioga Fastr X 20 x 1.75" front, Tioga Fastr X 20 x 1.60" rear
Seat: Elevn PC Pivotal
Seat post: Chase Aero Pivotal, 27.2 x 260mm alloy
Seat clamp: Chase Aero QR alloy, 31.8mm
Gearing: 44 x 16 (54.38" gear ratio)
Weight: 8.955kg (with pedals)
Note: Supplied with flat pedals. Shimano clips shown for display purposes only.

Assembly information

Your race bike ships mostly assembled in the box. Finishing it takes most people 10 to 20 minutes with basic tools, and the video above walks through every step.

Fit the handlebars and line them up with the front wheel
Fit the front wheel, pedals and seat post
Spin the rear wheel and check the rotor runs clear of the calliper
Check the brake and tyre pressure before the first ride

Disc brakes: keep your fingers off the rotor and pads, because oil from your skin contaminates the braking surface and takes the bite away. If the rotor rubs, loosen the two calliper bolts, squeeze the lever, then tighten them again with the lever held on. Bed the brake in with a few firm stops before you race it.

Tools: Allen key set and a 15mm spanner for the pedals. Check your axle hardware, since race bikes vary between bolt-on nuts and a thru-axle.

Rather have it done? Ask us about extra assembly before you order, or any local bike shop can finish the build for a small fee.

Chase Element Pro XXL Bike

Name: Chase Element Pro XXL Bike
Brand: Chase
SKU: 65CB220306PROXXLTL
Price: 2358.99 AUD
Availability: OutOfStock

Brand: Chase SKU: Click to copy the SKU and show the pick location

$2,358.99 AUD

Or 4 payments of $589.74 AUD with

Recommended Rider Height:

170-185cm+

Colour - Teal

Top Tube Length - 21.5

Race frames are sized by class, and the class you ride is set by rider height rather than age.

Size	Rider height	Top tube
Micro (18" wheels)	Under 120cm	16.25"
Mini (20" wheels)	110 to 140cm	17 to 18"
Junior	120 to 150cm	18.25 to 18.75"
Expert	130 to 170cm	19.5 to 19.75"
Expert XL	145 to 170cm	20 to 20.75"
Pro	150 to 175cm	20.25 to 20.75"
Pro XL	165 to 180cm	21 to 21.25"
Pro XXL	170 to 185cm and up	21.5 to 21.85"
Pro XXXL	175cm and up	22"
Pro XXXXL	180cm and up	22.5"
Cruiser (24" wheels)	175cm and up	21.5" and up

Heights overlap between classes on purpose. Where you land in two, a growing rider is usually better on the larger, and a rider who wants the bike to turn faster on the smaller. Some brands label the Pro size Pro L, with the same fit.

How to measure

Stand your rider against a wall in the shoes they ride in, heels flat, and mark the top of their head. Measure from the floor to the mark.

Between two sizes and still growing? Take the larger size.
Racing gates and wanting the bike to turn faster? Take the smaller size.
Top tube is the number that actually changes the fit, so compare it against the bike they ride now.

Not sure? Send us their height and we will tell you what we would put them on.
