Fiend Type R 20 Inch Bike / Matte Space Dust / 20.75TT

Highlights

Reynolds replica, Fiend's flagship frame
Full chromoly frame, fork, bars
Sealed freecoaster on Mylar rims
Alloy 25T sprocket, nylon guard

Description

Fiend Type R 20 Inch Bike (2022)

Garrett Reynolds is an absolute beast on the bike- so why wouldn't you want a rig just like his? The Type R is Fiend's flagship model gets it inspiration from Garrett's personal bike. The Type R has a full chromoly replica Reynolds frame with removable brake mounts, a full chromoly 9.25 rise handlebar, full chromoly Type A fork with CNCed steerer tube and tapered legs, 3-piece chromoly cranks with a sealed Mid bottom bracket, Fiend Reynolds PC pedals, alloy 25t Reynolds after-market sprocket with nylon Havoc guard, a fully sealed 14mm rear freecoaster hub, a sealed female axle front hub, Mission Mylar rims, a Fiend Reynolds Pivotal seat, Cinema Williams 2.50 tires, 4 steel pegs with nylon sleeves and Fiend flangeless Team grips.

Features

Reynolds replica, Fiend's flagship frame. The Type R takes its inspiration from Garrett Reynolds' personal bike: full chromoly with removable brake mounts.
Full chromoly frame, fork, bars. Chromoly through the frame, the tapered-leg fork with its CNC 1-piece steerer and the 9.25" rise bars, ready for street abuse.
Sealed freecoaster on Mylar rims. The Mission Deploy 14mm freecoaster with a 9T driver rolls backwards, laced to 36H Mission Mylar rims.
Alloy 25T sprocket, nylon guard. The Reynolds aftermarket sprocket saves weight and the nylon Havoc guard takes the hits on grinds.
Four pegs, 2.50" Cinema tyres. Steel pegs with nylon sleeves and Cinema Williams 2.50" street tyres, on a bike that is 11.5 kg without brake or pegs.

Specifications

Size: 20" wheels
Frame: Fiend Type R, full chromoly, removable brake mounts
Top tube: 20.75"
Chainstay: 13"
Fork: Fiend Embryo full chromoly, CNC 1-piece steerer tube, tapered legs
Stem: Fiend Matrix topload
Bars: Fiend Embryo chromoly, 9.25" rise
Grips: Fiend flangeless Team
Cranks: 165mm chromoly, 3-piece
Bottom bracket: Sealed Mid
Sprocket: Fiend Reynolds 25T alloy with nylon Havoc guard
Pedals: Mission nylon
Front hub: Mission Brigade sealed, female axle
Rear hub: Mission Deploy sealed freecoaster, 14mm, 9T driver (RHD)
Rims: Mission Mylar, 36H
Tyres: Cinema Williams 2.50" street
Seat: Fiend Reynolds 1-piece seat and post combo
Pegs: 4 steel with nylon sleeves
Weight: 11.5 kg without brake or pegs
Note: Specs subject to change without notice.

Assembly information

Your bike ships mostly assembled in the box. Finishing it takes most people 10 to 20 minutes with basic tools, and the video above walks through every step.

Fit the handlebars and line them up with the front wheel
Fit the front wheel, pedals and seat post
Check the brakes and tyre pressure before the first ride

Tools: Allen key set and a 15mm, 17mm or 19mm spanner for the pedals and axle nuts (bikes can vary between these three sizes). A socket is needed if installing pegs.

Rather have it done? Ask us about extra assembly before you order, or any local bike shop can finish the build for a small fee.

Fiend Type R 20 Inch Bike

Name: Fiend Type R 20 Inch Bike
Brand: Fiend
SKU: kabx2603
Price: 1249.99 AUD
Availability: OutOfStock

Brand: Fiend SKU: Click to copy the SKU and show the pick location

$1,249.99 AUD

Or 4 payments of $312.49 AUD with

Recommended Rider Height:

168cm+

Colour - Matte Space Dust

Top Tube Length - 20.75

A 20 inch bike is the standard adult BMX and suits riders from about 147cm up. At this wheel size the top tube is what changes the fit, so pick that by height.

Rider height	Wheel size	Top tube
60 to 91cm	12"	12 to 12.5"
81 to 106cm	14"	14 to 14.5"
96 to 122cm	16"	16 to 16.5"
122 to 147cm	18"	18 to 18.5"
147 to 157cm	20"	19.75 to 20.25"
157 to 168cm	20"	20 to 20.5"
168 to 175cm	20"	20.25 to 20.75"
175 to 183cm	20"	20.5 to 21"
183 to 190cm and up	20"	20.75 to 21.5"
160cm and up	22"	21 to 22.25"
160cm and up	24"	21.75 to 22"
160cm and up	26"	22 to 23"

Sizes overlap on purpose, so personal preference comes into it. If you land in two bands, riding style breaks the tie: longer for flow, trails and transitions, shorter for technical street and park.

How to measure

Stand your rider against a wall in the shoes they ride in, heels flat, and mark the top of their head. Measure from the floor to the mark.

Top tube is measured from the centre of the seat tube to the centre of the head tube, so it is not the same as the length of the tube you can see.

A 20 inch bike is the standard adult BMX and most riders end up there, so do not size a tall child down to a smaller wheel.
22, 24 and 26 inch bikes are adult bikes with a bigger wheel, not bigger frames for taller riders.
Size up for stability through trails and transitions. Size down if you want the bike quick and twitchy for spins and grinds.
Top tube is fixed, but stem length, fork offset and bar position all shift how roomy the bike feels once you are on it.

Not sure? Send us their height and we will tell you what we would put them on.

Read the full buying guide
