Description

The Rift ES20 Mini frame is here in all new colours for the 2023/24 race season. From classic grey charcoal with black decals, to hot pink, with a few colours in between, all of the frames are finished in a gloss clear coat covering the decals and adding an extra layer of protection. We reckon the kids will love these bright colours.

Rift haven't quite gone all the way with disc brake adaptation, with all of the youth frames sticking to a V-brake design, though we're 100% positive there will be disc brake conversions on the track for 2024. With a slotted 10mm dropout, there's plenty of caliper mount options out there.

Manufactured from 7005 Double Heat Treated Alloy, all of the main tubing is hydro-form making for a unique appearance. The CNC'd 3D dropouts are both beautiful and functional, and will for sure be dead straight making wheel installation dead easy.

A Euro bottom bracket means the crank install is also a quick and easy process. No messy silicon and multiple cable guides keeps your build looking sleek.

Rift frames are popular for good reason and the attention to detail on these has us excited to be offering them to you guys through LUX.

Note: The maroon and green frames here are the youth frames and are showing V-brake mounts. The other colours are pro frames and show the disc brake dropouts. These images are simply to display the colour options.

Features

  • Hydro-formed 7005 alloy frame. Double heat treated 7005 alloy with hydro-formed top tube, down tube and chain stays, and the decals sealed under a gloss clear coat.
  • V-brake mounts, 10mm slotted dropouts. The youth frames stay with V-brakes, and the slotted 10mm dropouts leave plenty of calliper mount options if you want to convert to disc.
  • CNC 3D dropouts. Machined to sit dead straight, so wheel installation is quick and the rear wheel lines up without any fiddling.
  • Euro bottom bracket shell. Cranks go in quickly, and the multiple cable guides keep the lines tidy without any messy silicon.
  • Mini race geometry. 17.75" top tube, 12.8" chainstay, 73° head angle and an 11.00" bottom bracket height, at 964g on 451mm wheels.

Specifications

  • Top tube: 17.75"
  • Chainstay: 12.8"
  • Head tube angle: 73°
  • Seat tube angle: 72°
  • Bottom bracket height: 11.00"
  • Bottom bracket: Euro
  • Material: 7005 double heat treated alloy
  • Tubing: Hydro-form top tube, down tube and chain stays, bulge seat tube, CNC chain stay yoke
  • Dropouts: CNC 3D, 10mm slotted
  • Brake mounts: V-brake
  • Cable routing: Multiple cable guides
  • Head tube: Integrated 1-1/8"
  • Seat tube: 22.2mm
  • Seat clamp: 24.5mm
  • Wheel size: 451mm (20 x 1-1/8 / 20 x 1-3/8th)
  • Weight: 964g

Rift ES20 Frame Mini

Brand: Rift SKU: Click to copy the SKU and show the pick location

Sale price$849.99 AUD

Or 4 payments of $212.49 AUD with

Colour - Gloss Maroon

Top Tube Length - 17.75


$849.99 AUD

Price match request

Rift ES20 Frame Mini - Gloss Maroon / 17.75

$12.99 flat-rate shipping Australia-wide

Express from $21.99

Free in-store pickup - Brisbane

Availability

17.75
Charcoal
Gloss Blue
Gloss Maroon
Gloss Green
Hot Pink

In stock at LUXBMX With supplier Preorder Sold out
