SD Ace Pro Bolt On Rear Disc Hub / Black / 36H/10mm

Description

The SD Ace Pro is a bolt on rear hub built around a CNC machined aluminium shell, with disc brake mounting and 10mm axle bolts. It runs sealed cartridge bearings and a six quadruple pawl driver for 180 points of engagement, so the pickup is quick when you stamp on the pedals.

It comes with an alloy axle and chromoly bolts, measures 110mm locknut to locknut, and is drilled 36 hole with 58mm flanges both sides. Available in black.

Features

180 points of engagement. Six quadruple pawls give 180 engagement points, so there is very little dead travel before the drive picks up.
Sealed cartridge bearings. Sealed cartridge bearings keep water and grit out, so the hub keeps spinning through wet riding.
Disc brake compatible. The shell takes a disc rotor, so it suits frames set up for disc braking.
CNC machined alloy shell. The hub shell is CNC machined aluminium, with an alloy axle and chromoly 10mm bolts.
36 hole, 110mm wide. Drilled 36 hole and 110mm locknut to locknut, with 58mm flanges on both sides for lacing.

Specifications

Fits: Disc brake frames, 110mm axle width (locknut to locknut)
Material: CNC machined aluminium hub shell
Bearings: Sealed cartridge
Engagement: 180 points
Driver: 6 quadruple pawl
Hole count: 36H
Axle: Alloy axle with chromoly bolts
Axle size: 10mm bolt on
Mount: Disc brake
Colour: Black
Note: Flange diameter 58mm both sides. Drive side flange to locknut 33mm, non-drive side 34mm.
